SSH-Series
Product Introduction
Feature
SSH Series
Specifications
| MODEL | JC-SSH-25D | JC-SSH-29DB | JC-SSH-29B | JC-SSH-35BB |
| Type of tooling | IPT"D" EU"D" |
EU"DB" | IPT"B" EU"B" |
IPT"BB" EU"BB" |
| Number of stations | 25 | 29 | 29 | 35 |
| Maximum Tablet diameter | 25.4mm (1" ) |
19mm(caplet) (3/4") |
16mm (5/8") |
13mm (33/64") |
| Production capacity (tablets/hour) * | 22,500-90,000 | 26,100-104,400 | 31,500-126,000 | |
| Revolution of turret / Min (60 cyc) | 15-60 RPM | |||
| Depth of fill adjustable to | 19mm (3/4") | 17mm (43/64") | ||
| Maximum operating pressure | 10,000kgs (22,000lb) | 6,000kgs (13,200lb) | ||
| Maximum pre-pressure | 10,000kgs (22,000lb) | 6,000kgs (13,200lb) | ||
| Diameter of die | 38.1mm (1.5") | 30.16mm (1.1875") | 24mm(0.945") | |
| Height of die | 23.81mm (0.9375") | 22.22mm (0.875") | ||
| Nominal diameter of punch body | 25.4 mm (1") | 19 mm(0.75") | ||
| Overall Length of upper Punch | IPT 133.35 mm (5.25") or EU 133.6 mm | |||
| Overall Length of lower Punch | IPT 133.35 mm (5.25") or EU 133.6 mm | |||
| Turret P.C.D | 365 mm | |||
| Power consumption | 3.0HP (2.2kw) | |||
| Machine dimensions | 750x895x1,580mm (H) (not including hopper) | |||
| Net weight | 1,800 kgs (3,960 lbs) | |||
